Description
Compatibility
- Compatible hub models : Hub Hybrid (2G) / Hub Hybrid (4G)
Communication
- Fibra communication technology : Two-way communication / Advanced anti-sabotage / Instant notifications / Remote configuration via the app
- Bus connection : 4-core cable
- Encrypted communication
- Bus line length : up to 2,000 meters when using the U/UTP cat.5 twisted pair.
- Detection
- Sensing element : 1 × PIR sensor / 1 × K-band microwave sensor
(When the device detects motion, it conducts an additional RF scan to eliminate false alarms) - Motion detection distance : up to 12 meters (When installed at 2.4 meters height)
- Motion detection angles : horizontal — 88.5° / vertical — 80°
- Motion detection speed : from 0.3 to 2.0 m/s
- Sensitivity : 3 levels
- Pet immunity : up to 20 kg / up to 50 cm height
- False alarm prevention : SmartDetect / Software algorithm / K-band microwave sensor
- Temperature compensation : Effective motion detection within −10°C to +40°C range
Anti-sabotage protection
- Tampering alarm
- Protection against forgery : Device authentication
Power supply
- Fibra line power supply : 24 V⎓, up to 50 µA
Enclosure
- Dimensions : 110 × 65 × 50 mm
- Weight : 96 g
- Operating temperature range : from −10°C to +40°C
- Operating humidity : up to 75%
- Protection class : IP50
