Description
- Classification : Radio channel relay unit
- Device type : Wireless
- Installation method :Into electric switchboard, junction box
- Compatibility : Operates only with Hub, Hub Plus, Hub 2 and ReX
- Actuating element : Electromagnetic relay
- Relay service life : 200,000 switch-ons
- Voltage protection : Max — 36.5 V, min — 6.5 V
- Maximum load current : 5A at 36V DC, 13A at 230V AC
- Maximum current protection : No
- Maximum temperature protection > 65°C at the place of installation
- Electric power meter function : No
- Energy consumption parameter check : Voltage
- Power supply : 7 – 24 V (DC only)
- Communication range with central unit — up to 1,000 m in an open space
- Two-way communication between devices
- Operating frequencies — 868.0 – 868.6 MHz
- Self-adjusting RF output power — up to 25 mW
- Block encryption based on AES algorithm
- Device scanning period — 12 – 300 s
- Operating temperature range : From 0°С to +64°С
- Permissible humidity : Up to 75%
- Protection class of body : IP20
- Anti-sabotage : Protection against fraud / Jamming detection
- Remote setting and testing : +
- Dimensions : 39 × 33 × 18 mm
- Weight : 25 g
- Certification : CE
- Warranty : Replacement and repair within 24 months of the date of sale
