Description
| Camera | |
| Image  Sensor | 1/2.8″ CMOS |
| Signal  System | PAL/NTSC |
| Min. Â Illumination | Color: 0.002Lux@ (F1.6, AGC ON), B/W: Â 0Lux with IR |
| Shutter  Time | 1s  to 1/100,000s |
| Day  & Night | Dual IR Cut Filter with Auto Switch |
| Wide  Dynamic Range | 120dB |
| Angle  Adjustment | Bracket, pan: 0° to 340°, tilt: 0° to 75°,  rotate: 0° to 360° |
| Lens | |
| Lens  Type | Fixed |
| Focus | 2.8mm |
| Lens  Mount | M12 |
| Aperture | F1.6, Fixed |
| FOV | Horizontal  field of view: 105.3° Vertical field of view: 56.9° Diagonal field of view: 127.9° |
| Illuminator | |
| IR Â LEDs | 2 |
| IR  Range | Up  to 30 m |
| Wavelength | 850nm |
| White  LEDs/Warmlights | 2 |
| Range | 15-20m |
| Compression  Standard | |
| Video  Compression | S+265/H.265/H.264 |
| Video  Bit Rate | 32  Kbps~16 Mbps |
| Audio  Compression | G.711A/G.711U/ADPCM_D/AAC_LC |
| Audio  Bit Rate | 8K~48Kbps |
| Image | |
| Max.  Resolution | 3840×2160 |
| Main  Stream | PAL：20fps（3840×2160,3072×2048）,25fps（2560×1440,2304×1296,1920×1080,1280×720） |
| NTSC: 20fps（3840×2160,3072×2048）,30fps（2560×1440,2304×1296,1920×1080,1280×720） | |
| Sub  Stream | PAL:  25fps(704×576,704×288,352×288,640×360） |
| NTSC: 30fps(704×480,704×240,352×240,640×360） | |
| Third  Stream | PAL：25fps(704×576,704×288,352×288,640×480） |
| NTSC:  30fps(704×480,704×240,352×240,640×480） | |
| Image  Setting | Saturation, brightness, contrast,  sharpness, adjustable by client software or web browser |
| Image  Enhancement | BLC/3D  DNR/HLC |
| ROI | 8 |
| OSD | 16×16, 32×32, 48×48,  64×64, 96×96, adaptable size,  Letters Such as Week, Date, Time, Total 3 Regions |
| Picture  Overlay | Yes |
| Privace  Mask | Yes,  4 regions |
| Smart  Defog | Yes |
| Feature | |
| Alarm  Trigger | Motion  Detection, Mask Alarm, IP Address Conflict |
| Video  Analytics | Tripwire, Perimeter |
| Early  Warning(EW) | Yes |
| Network | |
| ANR | Yes(Only  Support Tiandy ANR NVR) |
| Protocols | HTTP,HTTPS,TCP/IP,UDP,UPnP,ICMP,IGMP,SNMP,DHCP,DNS,DDNS,  Easy  DDNS,NTP,SSL,802.1X,QoS,IPV4,IPV6,PPPoE,SSH,Unicast,Multicast,RTCP,ARP,SRTP,RTMP |
| System  Compatibility | ONVIF  (PROFILE S/T/G), SDK, CGI,Milestone,P2P |
| Remote  Connection | ≤2 |
| Client | Easy7, Â EasyLive Plus |
| Web  Version | Web6 |
| Interface | |
| Communication  Interface | 1  RJ45 10M/ 100M self adaptive Ethernet port |
| Audio  I/O | 1/1 |
| Alarm  I/O | 1/1 |
| Speaker | Yes |
| Reset  Button | N/A |
| On-board  storage | Built-in  MicroSD card slot, up to 512 GB |
| General | |
| Web  Client Language | 17  languages Simplified Chinese/English/Traditional  Chinese/Spanish/Italian/Korean/Turkish/Russian/Thai/Polish/French/Dutch/Hebrew/Vietnamese/Arabic/German/Ukrainian |
| Operating  Conditions | -40℃～65℃, 0～95% RH |
| Power  Supply | DC  12V±25%, PoE (802.3af) |
| Power  Consumption | MAX: 6.5W(12V) MAX: 8W(POE) |
| Protection | IP67 |
| Heater | N/A |
| Dimensions | 117×117x84mm |
| Net  Weight | 0.5kg |
| Gross  Weight | 0.7kg |
