Description
Compatibility
- Compatible hub models :Hub Hybrid (2G) :Hub Hybrid (4G)
- Compatible range extenders : Range extenders with Fibra devices support will be soon added to the Ajax product line
Communication
- Fibra communication technology : Two-way communication / Advanced anti-sabotage protection / Instant notifications / Remote configuration via the Ajax apps
- Bus connection : 4-core cable
- Encrypted communication
- Bus line length : up to 2,000 meters when using the U/UTP cat.5 twisted pair
Detection
- Sensing element / 2 × reed switch (The magnet can be installed to the right or left side of the detector)
- Opening sensors resource : up to 2,000,000
- Additional detector connection : Wired detector with the normally closed (NC) contact type
- Anti-sabotage protection
- Tampering alarm
- Protection against forgery : Device authentication
Power supply
- Fibra line power supply : 24 V⎓, up to 45 µA
Enclosure
- Dimensions : 90.5 × 21 × 18.5 mm
- Weight : 54 g
- Operating temperature range : from −10°C to +40°C
- Operating humidity : up to 75%
- Protection class : IP50
