Tech specs
- Classification : Transponder for communication with the monitoring station via a VHF transmitter
- Installation : Indoors
- Number of potential outputs : 8
- Output types : Positive trip and negative trip (depends on the settings)
- Transmission types : Pulse and bistable (depends on the settings)
- Recommended VHF transmitters : Hawk VHF Alarm Transmitter from FSK Electronics / TX750C from RDC / TR-41 from Puper
- Compatible with Ajax range extenders : +
- Compatibility with third-party VHF radio transmitters : vhfBridge connects to any VHF transmitter with relay inputs
- Support for photo verification of alarms : No
- Primary power supply : 100–240 V, 50/60 Hz
- Backup power supply : 12 V DC, up to 75 hours of power for a transponder and a transmitter
- Supported battery type : 12 V battery with a full charge cycle of up to 30 hours. / The maximum battery size installed in the casing should be 150 × 64 × 94 mm
- Recommended battery type : 12 V battery with a capacity of 4 Ah or 7 Ah / Backup battery is not included in the set
- VHF transmitter power : 12 V DC, 2 A
- Anti-sabotage : Protecting against forgery / Jamming notifications / Tampers against opening and removal / Backup battery
- Jeweller radio protocol : Communication range — up to 1,800 meters in a line of sight / Two-sided communication between devices / Operating frequencies: 868.0–868.6 MHz / Auto-regulated radio signal power: ≤ 25 mW / Blocking encryption based on the AES algorithm / Detector ping interval: 12–300 seconds / Frequency hopping
- Maximum radio signal power : ≤ 25 mW
- Protection class : IP50
- Operating temperature range : From –10°C to +40°C
- Operating humidity : Up to 75%
- Overall dimensions : 196 × 238 × 100 mm (with casing) / 145 × 89 × 51 mm (without casing)
- Weight : 840 g (with casing) / 165 g (without casing)
