Description
BELINDA WSST IS TELETEK Point Fire Detection Beacon Siren
- Wall-mounted siren with flasher.
- 2 sound levels selectable from the panel – 85dB / 95dB.
- 32 sound types selectable from the panel.
- Loop powered.
- Place on a B124 base.
- Built-in loop isolator.
- Certified according to EN54 – 3/23 .
Technical Specifications:
- Operating voltage range 16 – 32VDC (nominal 27VDC).
- Nominal consumption (in standby mode) <500μA @ 27VDC Terminal cable diameter 2.5mm².
- Operating temperature -10° C to + 50° C.
- Protection IP21C Weight 183g.
- Dimensions (without base) 116x55mm.
- Maximum consumption (main tone type 27): – low volume level, sound only <5mA – low volume level and strobe <12mA – high volume level, sound only <16.5mA – high volume level and strobe <22mA
- Maximum consumption (other tone types): – low volume, sound only <4mA – low volume and strobe level <11mA – high volume, sound only <10mA – high volume and strobe level <16.5mA Consumption with isolator activated <15mA.
| Fire detection | |
| Isolator – Isolator | Yes |
| Sound Options | 32 |
| Agency Certification | EVPU |
| Certificate | EN 54 – 3/23 |
| Sound Level | DIP Switch setting 92 db / 100 db |
| Siren Type | Siren with Flash |
| Siren Use | Indoor – Outdoor with suitable base |
