Dahua PoE Cloud Gigabit Switch 4port +2UP 60W CS4006-4GT-60

Description

Hardware

• Included Power Adapter : Yes
• PoE : Yes
• Ethernet Port : 4
• Ethernet Port Speed : 10/100/1000 Mbps
• Ethernet Port Uplink Speed : 10/100/1000 Mbps
• Description of Function Slots : Port 1-4: 4 × RJ-45 10/100/1000 Mbps (PoE); Port 5-6: 2 × RJ-45 10/100/1000 Mbps (uplink)
• Reset Button : 1
• Power Supply : External power supply: 53 VDC, 1.226 A
• Operating Temperature : –10 °C to +55 °C
• Operating Humidity : 5%–95% (RH), non-condensing
• Storage Temperature : –40 °C to +70 °C
• Storage Humidity : 5%–95% (RH), non-condensing
• Power Consumption : Idling: ≤2.5 W Full load: 65 W

Performance

• Layer : Layer 2
• Management Type : Yes
• Smart Managed Switch : Yes
• MTBF : 222.36 years
• Switching Capacity : 12 Gbps
• Packet Forwarding Rate : 8.93 Mpps
• Packet Buffer Size : 4 Mbit
• Jumbo Frame : 15K Byte
• MAC Table Size : 8K
• VLAN Number : 32
• Communication Standard : IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab

Feature

• PoE Protocol : IEEE802.3af; IEEE802.3at; Hi-PoE
• PoE Power : Port 1 ≤ 60 W, Port 2-4 ≤ 30 W, total ≤ 60 W
• PoE Power Consumption Management : Yes
• PoE Pin Assignment : 1,2,4,5（V+）,3,6,7,8（V-）
• Long Distance PoE Transmission : Yes
• VLAN Function : Port-based VLAN
• IEEE 802.3x Flow Control : Yes
• DHCP Function : DHCP Client
• Equipment Management : Web management; App management

General

• Statics Protection : Air discharge: 8 kV; Contact discharge: 6 kV
• Lighting Protection : Common mode: 4 kV; Differential mode: 2 kV
• Net Weight : 0.29 kg
• Gross Weight : 0.94 kg
• Product Dimensions : 130 mm × 90 mm × 26 mm (L × W × H)
• Packaging Dimensions : 265 mm × 238 mm × 76 mm (L × W × H)
• Casing Material : Sheet metal
• Installation : Desktop mount; wall mount
