Description
Performance
- Layer : Layer 2
- Managed : No
- Switching Capacity : 7.2 Gbps
- Packet Forwarding Rate : 5.3568 Mpps
- Packet Buffer Memory : 4 Mbit
- MAC Table Size : 8K
- Standards Compliance : IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z
Hardware Feature
- Standard Power Supply : Yes
- PoE : Yes
- Ethernet Port : 16
- Optical Port : 2
- Ethernet Port Rate : 100 Mbps
- Optical Port Rate : 1 Gbps
- Number of Bussiness Card Slots : “Port 1–16: 16 × RJ45 10/100 Mbps / Port 17–18: 2 × RJ45 10/100/1000 Mbps (uplink) / Port 17–18: 2 × SFP 1000 Mbps (uplink) (combo)”
- Power Supply : 100V AC–240V AC
- Operating Temperature : –10°C to 55°C (14°F to 131°F)
- Operating Humidity : 10%–90%
- Storage Humidity : 5%–95%
- Power Consumption : “Idling: 5W / Full load: 135W”
PoE
- PoE Standard : IEEE802.3af, IEEE802.3at, Hi-PoE
- PoE Budget : Port 1–2≤60W, Port 3–16≤30W, total≤135W
- PoE Pin Assignment : PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) :
- Long Distance PoE Transmission : Yes
Function
- VLAN : Port Isolation
- QoS : Yes
- System Maintenance : PD Alive
General
- ESD : Air discharge: 8kV / Contact discharge: 6kV
- Thunderproof : Common mode: 4kV / Differential mode: 2kV
- Dimensions : 440 mm × 300 mm × 44 mm
- Packaging Dimensions : 527 mm × 412 mm × 110 mm
