Description
Hardware
- Data Transmission Port Port 1–8: 8 × RJ-45 10/100 Mbps (PoE) Port 9-10: 2 × RJ-45 10/100/1000 Mbps (Uplink)
- Power Supply 48 V – 57 V DC
- Operaing Temperatur –10 °C to +55 °C (+14°F to +131°F)
- Operating Humidit 5% – 95% (RH)
- Storage Temperature –20 °C to +70 °C (–4°F to +158°F)
- Storage Humidit 5% – 95% (RH)
- Power Consumptio Idling: 3 W Full load: 96 W
Performance
- Capacity 5.60 Gbps
- Packet Forwarding Rate 4.17 Mpps
- Packet Buffer Memory 4 Mbit
- MAC Table Size 8K
- Communication Standard IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x
PoE
- PoE Standard IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
- PoE Power 96 W
- Power Consumption Management Yes
- PoE Pin Assignment 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
- Long Distance PoE 250 m long distance PoE transmission
- PoE Watchdog Yes
General
- Statics Protection Air discharge: 8 kV Contact discharge: 6 kV
- Thunder-proof Common mode: 4 kV Differential mode: 2 kV
- Net Weight 0.50 kg
- Gross Weight 1.32 kg
- Product Dimensions 190 mm × 100 mm × 30 mm
