Description
Physical Features
System Linux
Front panel Plastic
Button Plastic button
Power supply PoE (802.3af) or DC12V/2A
Standby power 1.5W
Rated power 9W
Cameral 2MP, CMOS
Door Entry IC (13.56MHzZ) and ID (125kHz) card, PIN code
IP/IK Rating 1P65 / 1K08
Setup Flush Mounting
Surface Mount Dimensions 295x133x43mm
Flush Mount Dimensions 295x133x63.5mml
Working temperature -40°C – +55°C
Storage temperature -40°C – +70°C
Working Humidity 10%-90% (non-condensing)
View
View
4.3 inch TFT LCD
Resolution
480×272
Audio video
Audio Codec
G.711
Video Codec
H.264
Video resolution
1280×720
Angle of View
110°(H) / 67°(V) / 127°(V)|
Light Compensation
LED white light
Networking
Protocol
SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP
Connection Points
Port of Wiegand
Support
Ethernet Port
1 x RJ45, 10/100 Mbps adaptive
RS485 Port|
1/
Relay Output
3
Restart button
1/
Entrance
4
