Description
IRIS 4 TELETEK Network Point Fire Detection Panel
- Up to 4 loops & 96 zones in a high-end gray metal box.
- Teletek Electronics protocol – 250 devices per loop.
- Each loop has 2 built-in isolators. Quick and easy programming. (Proste & Keyboard) Each device has the ability to describe up to 40 symbols.
- Day/Night mode.
- Up to 128 programmable inputs/outputs – freely programmable.
- It has a 5″ color touch screen
- Up to 64 panels on a network (TCP/IP protocol) – Local monitoring software (Observer)
- Ethernet input for programming and monitoring.
- Possibility of remote access and management via Cloud Server.
- Management & updates via notifications for IOS & Android devices.
- Management & update via email on PC – ability to view all tables in a technician’s tab.
- USB input for software version upgrade.
- Possibility of using a repeater.
- Dual device address detection capability
- Ability to detect and locate short circuits.
- Expansion card with galvanic isolation.
- Possibility of automatic device registration (Auto addressing).
- Multilingual support – Coming soon with Greek menu.
- Recording of 10000 events.
- Supports loop expansion for System Sensor Protocol – 198 devices per loop (99 detectors / 99 units).
- Metal Facade.
- Certification / Compliance EN54-2/4.
Technical Specifications:
- Main power supply ~ 230 VAC +10% / – 15%.
- Frequency 50/60Hz.
- Backup power supply 1 battery, 12V / 18Ah.
- Electrical power 7A.
- Operating temperature -5°C to +40°C.
- Weight (without battery) 6 kg.
- Color Gray.
- Dimensions 430x330x120mm.
| Fire detection | |
| Remote Control | Via Smartphone |
| Handling & Management Languages | Greek – English |
| Warranty | 2 Years |
| Fire Detection Zones | 96 |
| Maximum Panel Capacity (Loop) | 4 |
| Agency Certification | EVPU |
| Certificate | EN 54 – 2/4 |
| Capacity per Loop | Up to 250 |
