Description
MAG8PLUS TELETEK Fire Detection Panel
- Expandable fire detection panel up to 16 zones.
- Supports up to 512 detectors and call buttons without numerical limit.
- To prevent false alarms, the detector can be activated twice (Double knock) at a specific time. Supports up to 8 sirens on 2 outputs.
- Supports siren expansion cards.
- Supports relay expansion cards.
- Supports event card Output delay – Siren activation delay (1-10min).
- End-of-line resistor (EOL) allowing continuous monitoring of inputs. 2 access levels (Panel Lock) are protected by the use of a key on the front of the panel.
- Very easy to install. No programming required.
- Ability to connect to an answering machine and send signals to a Signal Receiving Center.
- Fault, Fire notification and remote system control via application.
- Certified according to European standards EN54-2/4.
Technical Specifications:
- Power supply 230VAC ± 10% fuse 0.63A.
- Auxiliary output 24 VDC / 0.3A.
- Battery 12 V / 18 Ah (Not included).
- Operating temperature -5°C to +40°C.
- Weight (without battery) ~ 4kg.
- Dimensions: -metal bottom 441x331x80mm -plastic cover 461x344x45.
| Fire detection | |
| Number of Sirens / Output (1st option) | Up to 3 internal Sirens SF105 / SF50 |
| Number of Sirens / Output (2nd option) | From 1-13 and from 1-30 internal sirens SF100 RSST, SF100RSND-SF100WSST depending on the sound type |
| Double Knock | Yes |
| Warranty | 4 Years |
| Output / Command per zone | Yes using MR8 |
| Expandable Table | Yes |
| Agency Certification | EVPU |
| Certificate | EN 54 – 2/4 |
| Adjustable Output Delay | Yes |
| Using a Repeater | Yes |
