Description
SensoIRIS BSOU TELETEK Point Fire Detection Siren and Base
- Wall-mounted siren and base for fire detector (T110, S130, M140).
- 2 sound levels selectable from the panel – 92dB/ 100dB.
- 32 sound types selectable from the panel.
- Loop powered.
- Built-in loop isolator.
- Certified according to EN54 – 3/23 .
Technical Specifications:
- Operating voltage range 15 – 32VDC, Nom. 28VDC.
- Maximum consumption in communication 470 mA @ 27VDC Maximum consumption, tone type 27, low volume level 2.8 mA @ 27VDC Maximum consumption, tone type 27, high volume level 9.8 mA @ 27VDC.
- Total number of SensoIRIS BSOU in loop – low level 100 pcs.
- Total number of SensoIRIS BSOU in loop – high level 30 pcs.
- Number of tone types 32 Material, color ABS, white.
- Dimensions with assembled SensoIRIS T110 (IS) / S130 (IS) detector 102 x 63mm.
- Dimensions with assembled SensoIRIS M140 (IS) detector 102 x 70mm.
| Πυρανίχνευση | |
| Βάση στην Σειρήνα | Ναι |
| Πιστοποίηση Φορέα | EVPU |
| Πιστοποιητικό | EN 54 – 3 |
| Στάθμη Ήχου | Ρύθμιση με DIP Switch 92 db / 100 db |
| Τύπος Ήχου | 32 |
| Χρήση Σειρήνας | Εσωτερική |
