Description
SensoIRIS WS TELETEK Point Fire Detection Flashing Siren
- Wall-mounted siren with flash. 2 sound levels selectable from the panel – 92dB / 100dB.
- 32 sound types selectable from the panel. Loop powered.
- Place on a B124 base.
- Built-in loop isolator.
- Certified according to EN54 – 3/23 .
Technical Specifications:
- Operating voltage range 15 – 32VDC (nominal 27VDC).
- Nominal consumption (in standby mode) <500μA @ 27VDC.
- Terminal cable diameter 2.5mm².
- Operating temperature -10° C to + 50° C.
- IP43C protection.
- Weight 183g.
- Dimensions (without base) 116x55mm.
| Fire detection | |
| Sound Options | 32 |
| Agency Certification | EVPU |
| Certificate | EN 54 – 3 |
| Sound Level | DIP Switch setting 92 db / 100 db |
| Siren Type | Siren with Flash |
| Siren Use | Indoor – Outdoor with suitable base |
