AJAX FIBRA HomeSiren White (Requires License)

Description

• Compatibility
  • Compatible hub models : Hub Hybrid (2G) /Hub Hybrid (4G)
  • Compatible range extenders : Range extenders with Fibra devices support will be soon added to the Ajax product line

  Communication

  • Fibra communication technology : Two-way communication / Advanced anti-sabotage / Instant notifications / Remote configuration via the Ajax apps
  • Bus connection : 4-core cable
  • Bus line length : up to 2,000 meters when using the U/UTP cat.5 twisted pair

  Key features

  • Alarm type : Acoustic / Built-in buzzer
  • Alarm volume : from 81 to 105 dB at a distance of 1 m
  • (Adjusted by PRO or user with admin rights in the Ajax app)
  • Alarm duration : from 3 to 180 s (Adjusted by PRO or user with admin rights in the Ajax app)
  • Siren sound frequency : 3.4 ± 0.5 kHz
  • Additional LED connection : 3 V (external LED works in parallel with the LED built into the siren and fully replicates its indication)
  • Chime : The siren makes a special sound to notify that the opening detectors are triggered when the system is disarmed
  • Events indication :  Alerts / Entry/exit delays / Security mode / Security mode changing / After-alarm indication

  Anti-sabotage protection

  • Tampering alarm : Alerts of attempts to detach the siren from the surface or remove the mounting panel
  • Protection against forgery : Device authentication

  Power supply

  • Fibra line power supply : 24 V⎓, up to 50 µA (The siren is powered by the control panel)

  Enclosure
  Dimensions : 90.5 × 90.5 × 33 mm
  Weight : 84 g
  Operating temperature range : from −10°C to +40°C
  Operating humidity : up to 75%
  Protection class : IP50
