Description
Compatibility
- Compatible hub models : Hub Hybrid (2G) / Hub Hybrid (4G)
Communication
- Fibra communication technology : Proprietary wired communication technology. Fibra combines the reliability of wires with the freedom of radio connection. It features: Two-way communication / Advanced anti-sabotage / Instant notifications / Remote configuration via the app
- Bus connection: 4-core cable
- Encrypted communication
- Bus line length : up to 2,000 meters / When using twisted pair U/UTP cat.5
Key features
- Alarm type : acoustic and LED / Buzzer and LED frame
- Alarm volume : from 85 to 113 dB at a distance of 1 m / Adjusted by PRO or user with admin rights in the Ajax app
- Alarm duration : from 3 s to 3 min / Adjusted by PRO or user with admin rights in the Ajax app
- Siren sound frequency : 3.5 ± 0.5 kHz
- Chime : The siren makes a special sound to notify that the opening detectors are triggered when the system is disarmed
- Events indication : Alerts / Entry/exit delays / Security mode / Security mode changing / After-alarm indication
Anti-sabotage protection
- Tampering alarm : Alerts of attempts to detach the detector from the surface or remove the mounting panel
- Protection against forgery : Device authentication
Power supply
- Fibra line power supply : 24 V⎓, up to 46 mW / The Siren is powered by the control panel
Enclosure
- Dimensions : 198.5 × 198.5 × 58 mm
- Weight : 575Â g
- Operating temperature range : from −25°C to +60°C
- Operating humidity : up to 95%
- Protection class : IP54
